Red Arrow 13W Round Emergency LED Gear Tray Daylight

This is a Product image
Quick Find: 56470

Product Discontinued
This item was discontinued on 27th March, 2025

Alternatively check out our full range of simular products below:
Red Arrow Emergency Lighting

Beam Angle
120 Degrees

Colour Temp
5700 K

Depth
30 mm

Diameter
245 mm

Dimming?
Non-Dimmable

Emergency Type
Maintained

Equivalent Wattage
28 W

Finish
Grey

IP Rating
IP20

Light Colour
Daylight (860/865)

Light Fitting Type
Gear Tray

Lumens
1800 lm

Manufacturer
Red Arrow

Technology
LED

Type
Light Fitting

Voltage
220-240 Volt

Wattage
13 W

Product Overview

Red Arrow 13W Round Emergency LED Gear Tray Daylight from Red Arrow

Model: GTC13E-57

A 13 watt aluminium gear tray designed to be compatible with the discus and Polo range of bulkhead fittings. This gear tray will emit a 1800lm daylight colour temperature and has a 40,000 hour lifespan. Ideal for use in factories, warehouses and hotels. This round gear tray benefits from an additional emergency mode function, where a minimum of 3 hours of emergency lighting will be provided if/when required. Made from a durable polycarbonate design for strength and durability. Dimensions: Diameter: 245mm x Depth: 30mm. Supplied with Emergency Conversion Battery. Suitable for POLB and D3BHLT/D3WHLT Empty Body Bulkheads.

Technical Specifications

Light Fitting Type Gear Tray
Technology LED
Wattage 13 W
Manufacturer Red Arrow
Light Colour Daylight (860/865)
Dimming? Non-Dimmable
Equivalent Wattage 28 W
Beam Angle 120 Degrees
Lumens 1800 lm
Colour Temp 5700 K
Depth 30 mm
Diameter 245 mm
Type Light Fitting
Finish Grey
Manufacturers Average Lamp Life 40000 hrs
Voltage 220-240 Volt
IP Rating IP20
Warranty 5 Years
Emergency Type Maintained
Alternative Part Number E15LEDEM-60

Associated Product Barcodes

5055807615495
5055807622004

Alternative Stock Identifier Part Codes
