Tridonic Advanced 15W LCI 350mA stepDIM Compact Dimming LED Driver Ip
Quick Find: 54360
Part No: 89800277
In Stock
Available for delivery
Available for delivery
Price
£22.50
Inc. VAT
£27.00
RRP
£29.97
25% Off
Save a total of £7.47
Save a total of £7.47
£22.50
Inc. VAT £27.00
Inc. VAT £27.00
Saving 25% (£7.47) on RRP: £29.97
Quick Find: 54360
Part No: 89800277
Accessory Type
LED Driver
Control Gear Technology
LED
Current Output
350mA
Depth
21 mm
Dimming?
Dimmable
Height
20 mm
Input Voltage
220-240 V
Length
179 mm
Manufacturer
Tridonic
Material
Polycarbonate
Output Voltage (LED Driver)
51 V
Type
Control Gear
Voltage
21-46 Volt
Wattage
15 W
Width
30 mm
Tridonic Advanced 15W LCI 350mA stepDIM Compact Dimming LED Driver Ip from Tridonic
Model: 89800277
The Tridonic Advanced 15W LCI 350mA stepDIM Compact Dimming LED Driver with IP rating is designed for efficient and reliable LED lighting control. It provides a constant current output of 350mA, with a maximum power capacity of 15W.
The stepDIM functionality allows for straightforward dimming control by toggling between two preset brightness levels using a standard switch. This is ideal for applications where simple, effective dimming options are needed without complex controls.
The compact design ensures that the driver can be easily integrated into a wide range of lighting fixtures, making it suitable for both residential and commercial environments. The IP rating indicates that the driver offers protection against dust and moisture, enhancing its durability and suitability for various environmental conditions.
Overall, the Tridonic Advanced 15W LCI 350mA stepDIM Compact Dimming LED Driver provides a reliable, high-quality solution for dimmable LED lighting, combining ease of use with robust performance.
Technical Specifications
| Accessory Type | LED Driver |
|---|---|
| Wattage | 15 W |
| Manufacturer | Tridonic |
| Dimming? | Dimmable |
| Depth | 21 mm |
| Height | 20 mm |
| Input Voltage | 220-240 V |
| Length | 179 mm |
| Type | Control Gear |
| Manufacturers Average Lamp Life | 50000 hrs |
| Voltage | 21-46 Volt |
| Material | Polycarbonate |
| IP Rating | IP20 |
| Current Output | 350mA |
| Warranty | 5 Years |
| Width | 30 mm |
| Rated Supply Voltage | 220-240V |
| Mains Frequency | 0/50/60 Hz |
| Operating Mode (Constant Current / Constant Voltage) | Constant Current |
| Max. Output Power | 15 Watts |
| Output Voltage (LED Driver) | 51 V |
| Control Gear Technology | LED |
Alternative Stock Identifier Part Codes
Components
For Tridonic Advanced 15W LCI 350mA stepDIM Compact Dimming LED Driver Ip
Downloads
 | Datasheet |
